Large Diameter Fiber Cleaver（FC-100）
Product Description
The FC-100 Large Diameter Fiber Cleaver is mainly designed for cleaving fibers (≤1500um) and fiber combiners. Users can easily cleave different types of fibers by simply setting the fiber tension and advancing the cutter head before cleaving. The device features the cleaving stability required for production and the flexible adjustability essential for R&D work.
Features
? Built-in high-capacity lithium battery
? Cleave for 125~1500μm fibers
? Automatic tension control
? Average blade life: 3000 cleaves
Specification
Parameter | Unit | Specification |
Fiber Cladding Diameter | um | 220~1500 |
Tension Range | gf | 0~5000 |
Cleaving Angle | ° | <0.5 |
Fiber Fixture Displacement Length | mm | 32~80 |
Cutter Head Step | um | 1~3 |
Blade Life | - | 3000 (for 400μm DCF with 1250gf tension) |
Working Humidity | %RH | 50~60 |
Power Supply | - | AC 110~220V 50/60Hz; DC 12.6V 5A |
Dimension（L*W*H） | mm | 258×152×169 |
Standard Accessory List
Accessory | Model | Unit | Quantity |
Large-diameter Fiber Cleaver | FC-100 | set | 1 |
Power Adapter | - | set | 1 |
Fiber holder | FH- (Provide according to the size request) | pair | 1 |
Certificate of Conformity | - | copy | 1 |
Warranty Card | - | copy | 1 |
User Manual | - | copy | 1 |
Portable Carrying Case | - | piece | 1 |
